Salient Features

• Rated up to 415 V, 50 Hz, 3-phase, 4-wire system
• Current Rating: Up to 4000 A
• Short Circuit Withstand: Up to 65 kA for 1 sec
• Ingress Protection: IP-42 / IP-52 / IP-65 (as required)
• Modular, compact, and robust design
• Easy accessibility for maintenance and cable termination
• Suitable for indoor or outdoor installation

 Constructional Highlights

• Enclosure: Fabricated from high-quality CRCA sheet steel, powder-coated with epoxy-polyester finish for corrosion resistance.
• Bus Bars: High-conductivity electrolytic copper or aluminum, fully insulated and color-coded for phase identification.
• Compartmentalization: Segregated sections for incomer, bus bar, and outgoing feeders to enhance safety and serviceability.
• Cable Entry: Top or bottom cable entry provision as per site requirement.
• Mounting: Free-standing, wall-mounted, or pedestal-mounted type.

Electrical Components

• Incomer: ACB / MCCB / SFU / Isolator with or without metering
• Outgoings: MCCBs / MCBs / Contactors / Switch Fuses
• Metering: Digital multifunction meters for voltage, current, kW, PF, frequency, and energy
• Indication: LED indication lamps and pushbuttons
• Protection: Overload, short-circuit, and earth fault protection

Testing & Quality

Every LT panel is routinely tested as per IS/IEC standards for:

• High-voltage dielectric test
• Insulation resistance test
• Functional operation test
• Visual and mechanical inspection..
• All panels undergo thorough quality checks to ensure performance, reliability, and compliance with the client’s technical specifications.

Applications

• Industrial Plants and Process Industries
• Commercial Buildings and Complexes
• Power Utilities and Substations
• Infrastructure and Public Facilities
• Renewable Energy Projects (Solar / Wind)
